Product Description
The RION PV-95 is a compact, high-sensitivity shear-type piezoelectric accelerometer designed for precision vibration measurement across a wide frequency range. It features a top-mounted BNC connector configuration, analog DC charge output, shielded construction, low pyroelectric noise inherent to shear-type designs, and is suited for general-purpose vibration analysis, structural testing, equipment diagnostics, and modal analysis. The PV-95 is the top-connector variant of the PV-94/95 pair within RION's PV Series, covering frequencies from 1 Hz to 10,000 Hz with a mounting resonance frequency of 36 kHz.(Missing cable)
Technical Specifications
| Specification | Value |
|---|---|
| Brand | RION |
| Model / Part Number | PV-95 |
| Product Type | Piezoelectric Accelerometer |
| Measurement Principle | Shear |
| Sensing Technology | Shear Piezoelectric |
| Sensitivity Classification | High Sensitivity Type |
| Charge Sensitivity | 0.714 pC/(m/s²) @ 80 Hz (representative value) |
| Mass (Weight) | 9 g |
| Vibration Frequency Range (±1 dB) | 1 Hz to 10,000 Hz |
| Mounting Resonance Frequency | 36 kHz |
| Maximum Measurable Acceleration | 10,000 m/s² (peak) |
| Transverse Sensitivity | 4% or less |
| Temperature Range for Use | -50°C to +160°C |
| Connector Location | Top-mounted |
| Termination Type | BNC |
| Output Type | Charge output (pC) — Analog |
| Current Type | DC |
| Pressure Type | Dynamic |
| Shield | Shielded |
| Compatible Mounting Type | Stud Mount |
| Dimensions (approx.) | φ24 mm × 27 mm (H) |
| Mounting Thread | M6, depth 4.5 mm |
| Connecting Capacitance | 30.5 pF |
| Standard Supplied Cable | VP-51A (2 m) |
| Series | PV Series |
| Manufacturer | RION Co., Ltd. |
We warranty all items for 30 days from date of purchase.
Other Details
We warranty all items for 30 days from date of purchase. If you experience any issues with your item within this period, please contact us and we will work with you to resolve the problem. This warranty covers defects in functionality but does not cover damage caused by misuse, improper installation, or normal wear and tear.Product Videos
Custom Field
GTIN 679523686222
Output Type Analog
Sensor Type Piezoelectric Accelerometer
Country/Region of Manufacture Japan
Dimensions φ24 mm × 27 mm (H)
Mount M6, depth 4.5 mm
Frequency 1 Hz to 10,000 Hz (±1 dB)
Ratio 10,000 m/s² peak
Manufacturer Rion
Cable VP-51A (2 m)
Part Number PV-95
Series PV Series
Shelf K-36
Model PV-95
MPN PV-95
Type Pressure Sensor
